FA230/231-8AL Pneumatic Foot Valve Two Position Three Way Normally Open / Closed
Specifications
| Model | FA – 230 | FA – 2301 |
| Port Size | 8A |
| Port Size | Rc 1 / 4 |
| Port | 3 |
| Position | 2 |
| Working Medium | Filtered Compressed Air |
| Ambient and media temperature | 5 – 60 ℃ |
| Ensured Pressure Resistance | 1 . 0 MPa ( 10kgf / cm ² ) |
| Working Pressure | 0 . 2 – 0 . 8 MPa (2 – 8 kgf / cm ² ) |
| Effective Sectional Arra | 8 mm ² |
Port Size G , NPT avilable in addition .
Fesatures
Small body , big flux , simple andconvenient operation .
Protecrive cover allowed .
Flowmeter
| P . ( MPa ) | P2 | Q ( m ³ / h ) |
| 0 . 8 | 0 . 7 | 29 |
| 0 . 7 | 0 . 6 | 27 |
| 0 . 6 | 0 . 5 | 24 |
| 0 . 5 | 0 . 4 | 22 |
| 0 . 4 | 0 . 3 | 19 . 5 |
| 0 . 3 | 0 . 2 | 16 . 7 |
| 0 . 2 | 0 . 1 | 14 . 2 |
Applications
FA series foot pedal valve manual operated use for fast direction change of anywhere and anytime necessary
function required by manual operating,Due to easy and flexible operating,it was widely use in the Pneumatic system
